Newpowa 10W(Watts) 12V(Volts) Monocrystalline 10BB Solar Panel High-Efficiency PV Module Power for Boat RV Gate Opener Fences

Price: $26.49
(as of Feb 20, 2026 09:26:13 UTC – Details)

Product description

1 About NEWPOWA

2 U.S. Local Warehouse

3 ​R&D, Production&Testing

4 Problem Solving

1 For RV

2 For Marine

3 For Rooftop

4 For Outdoors

Model NPA10S-12J Power Output 10W Voltage MPP Vmp 18.34V Current MPP Imp 0.55A Voltage Open Circuit Voc 21.57V Short Circuit Current Isc 0.59A Temperature Coefficient Of Voc -(80±10)mV/°C Temperature Coefficient Of Isc (0.065±0.015)%/°C Cells Monocrystalline Silicon Solar Cells Grade Class A High Efficiency Module Dimension(in./mm) 17.32[440]x8.46[215]x0.71[18] Weight(lbs/kg) 2.34[1.06]

Does a Solar Panel produce full power?

In most cases, it is normal for a solar panel to not be able to provide its full nominal power.

Factors affecting the performance of solar panels: Peak Sun Hours， Sunlight Angle， Operating Temperature， Installation Angle， Panel Shading, Etc…

How to test a solar panel?

The ideal conditions: Noon, clear sky, 25° tilt to the sun, battery is less than 40% SOCC. Disconnect the solar panel from any other loads, using a multimeter to test the panel’s current and voltage.

How does temperature affect solar panel efficiency?

Solar Panel Efficiency & Temperature: -Test Temp: 77°F/25°C; -Peak Efficiency Range: 59°F/15°C to 95°F/35°C; -​Temp Impact: Efficiency decreases with temperature rise. ​-Example: Temp coefficient of -0.5% → Power reduces by 0.5% per 50°F/10°C rise.

How to install our solar panels using different brackets?

There are mounting holes on the panel frame for easy installation using a variety of brackets. Most compatible with Newpowa’s Z-mount, tilt-adjustable mount, and pole/wall mount, making panel mounting suitable for a variety of applications.

Can I connect different solar panels together?

Though mixing different solar panels is not recommended, the mismatch can be achievable as long as each panel’s electrical parameters (voltage, current, wattage) are carefully considered.

Solar Panel

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.4 out of 5 stars 624

4.5 out of 5 stars 321

4.5 out of 5 stars 253

4.5 out of 5 stars 321

4.3 out of 5 stars 34

4.5 out of 5 stars 1,653

Price

$26.49$26.49

$49.99$49.99

$44.99$44.99

$75.99$75.99

$79.99$79.99

$69.99$69.99

MAX Watt

10W

35W

50W

60W

80W

100W

Cell Type

Monocrystalline

Monocrystalline

Monocrystalline

Monocrystalline

Monocrystalline

Monocrystalline

Dimension(in./mm)

17.32[440]x8.46[215]x0.71[18]

20.67[525]x15.75[400]x1.10[28]

23.07[586]x19.88[505]x1.18[30]

22.24[565]x23.03[585]x1.18[30]

28.74[730]x22.83[580]x1.18[30]

36.61[930]x22.83[580]x1.18[30]

Weight(lbs/kg)

2.34[1.06]

5.33[2.42]

7.74[3.51]

8.77[3.98]

10.19[4.62]

12.74[5.78]

System Voltage

12V

24V

12V

24V

12V

12V

【New Design】High-performance mono cells encapsulated in EVA ensure excellent conversion rate up to 21-23%.
【Dimension】17.32*8.46*0.71Inch. High winds (2400PA) and snow loads (5400PA).
【Maximum power (Pmax)】10W, Voltage at Pmax (Vmp):18.34V, Current at Pmax (Imp): 0.55A.
【Easy Installation】This solar panel is with a pair of pre-attached 3ft with bare ends.
【After-sales Service】 With a 2-year material and parts workmanship assurance.10 years of power output is greater than 90%, 25 years of power output is greater than 80%.
