5500W Solar Inverter 48V to 110V/220V, 5.5kW Off-Grid Hybrid Inverter w/ 120A MPPT Charge Controller Built-in, Pure Sine Wave Inver-TER for 48V Lead-Acid and Lithium Battery 220V

Price: $568.99
(as of Feb 09, 2026 12:08:55 UTC – Details)


Off-Grid 5500W Solar Inverter Pure Sine Wave 48V Built in 60A MPPT Controller
【PRODUCT FEATURES】
– Compatible with mains voltage or generator power
– Overload and short circuit protection
– Intelligent battery charger design for optimized battery performance
– It is a low PV input voltage inverter, it must work with 48V battery
【INPUT】：
Single Phase：L+N+PE
Rated Input Voltage：110/220
Voltage Range:90-280VAC+3V(Normal Mode)170-280VAC + 3V
Frequency Range:50Hz/60Hz(Adaptive)
【OUTPUT】：
Rated Output Power:5500W
Output Voltage:110V/120V/220V/240VAC+5%
Output Frequency:50/60Hz+0.1%
Waveform：Pure Sine Wave
Switch Time：10ms(Typical)
Peak Power：11000VA
Overload Capacity：10.5s@110%-150% Load;5.5s@150%-200% Load ;200ms@>200% Load
Peak Efciency：＞94%
【BATTERY】：
Rated Voltage：48Vdc
Constant Voltage Charging Voltage：56.4Vdc
Float Charging Voltage：56.4Vdc
【CHARGER】：
pV Charging Method：MPPT
pV Maximum Input Power:5500W
MPPT Input Voltage Range:120-500Vdc
Optimal working range ofVmp:300-400Vdc
Maximum Py Input Voltage:500Vdc
Maximum Py Input Current:20A
Maximum AC Charging Current:100A
Maximum AC Input Current:80A
Maximum Charging Current:120A
【DISPLAY】：
LCD Interface：Operating /Load /Input /Output…
【COMMUNICATION】：
Embedded Interfaces：BMS/RS232/RS485 /CAN / USB /Dry Contact
Parallel Interface：Yes
Noise:＜50db
Dimension：536*352*135mm
Net Weighr(kg)：10.5
【CUSTOMER SERVICE】
If you have any questions, please contact us and we will will reply sooner.(within 24 hours). I wish you a happy life!
【SOLAR HYBRID INVERTER】5500W Solar Hybrid Inverter 48V DC to AC 110/120/220/230/240V, built in 120A Mppt charge controller, which combines all the functions of an inverter, solar charger and battery charger.
【ALL IN ONE INVERTER】Rating Ouput Power: 5500W, Max.PV Input Power: 5500W, Voltage range: 120-500Vdc, Max. PV Input VOC: 500V DC; Max.charging current: 120A(AC+solar).
【HYBRID INVERTER w/LCD DISPLAY】LCD display design for dynamic display of data and operating status.Support WIFI remote monitoring, users can monitor the status of the PV from the mobile phone or from the website anytime anywhere.
【FULL CHARGING PROTECTIONS】The hybrid inverter has power failure protect, overload/overcurrent/lightning protection/low voltage/short circuit protection. Adopting reliable aluminium alloy material, it can dissipate heat efficiently.
【WIDE RANGE OF USES】MPPT Inverter Charger Pure sine Wave 5500W for RV Camping Boat Home Emergency ect. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads.
