200W Portable Solar Panel Kit,23.5% High Efficiency 12BB Cells,Ultra-Thin 1.6mm Tempered Glass,20A PWM Controller, IP68 Waterproof,Foldable Lightweight for RV,Off-Grid,Camping,Outdoor Power Station

Price: $147.98 - $139.99
(as of Jan 31, 2026 12:50:46 UTC – Details)

Product description

Maximum Power for Big Adventures, Fast Charging & High Capacity Output

Unleash true off-grid freedom with 200W of solar power—perfect for RV road trips, cabins, emergency backup, and group camping. High-efficiency 23.5% Grade A+ cells deliver rapid charging, even for multiple devices or large power stations. Double the power for faster charging and longer runtime. Easily power fridges, laptops, lights, and more—ideal for families, teams, or extended outdoor stays. Get reliable, high-capacity energy wherever you are.

Pro-Grade Compatibility & 20A Smart Controller

Effortlessly charge most portable power stations and 12V batteries. The advanced 20A PWM controller supports higher current for large-capacity batteries and multiple devices. Multiple connection options (alligator clips, Anderson, XT60, DC5521, DC7909) make every setup simple easier.

PWM Controller User Manual

Key Benefits of This PWM Controller

Intelligent 3-Stage PWM Charging: Maximizes battery life and charging efficiency with automatic multi-stage management. Multiple Safety Protections: Built-in protection against short circuit, overcharge, overload, reverse polarity, and open circuit for operation. Industrial-Grade Microcontroller: Delivers stable, reliable performance in all weather. Large, Clear LCD Display: All parameters are adjustable; real-time system status at a glance. Dual MOSFET Reverse Current Protection: Minimizes heat and maximizes safety.

How to Use Your PWM Solar Charge Controller

Connect your battery first: This allows the controller to detect your battery type and operate safely. Next, connect the solar panel. Finally, connect your devices (load) if needed. When disconnecting, reverse the steps

Important Safety Tips

Only for lead-acid batteries (OPEN, AGM, GEL). Not compatible with lithium, NiMH, or other battery types; Ensure sufficient battery voltage before first use, so the controller can recognize your battery; Keep battery cables as short as possible to reduce power loss. Solar use only: Do not connect other charging sources (like mains chargers) to the controller.

Rugged & All-Weather Performance, Easy Setup & Adjustable for Maximum Sun

Built for the toughest conditions—IP68 waterproof, ultra-durable 1.6mm tempered glass, and a reinforced aluminum frame. Count on stable power in rain, snow, or intense sun. Multi-angle kickstands ensure you always catch the best sunlight. Set up in seconds—power up quickly, no matter where your adventure takes you.

Complete Pro Solar Kit

Includes everything you need: 200W solar panel, stylish protective bag, 4-in-1 solar cable, 20A PWM controller with 4m alligator clips, 3m Anderson extension, and user manual. Ready for any high-demand scenario—outdoor adventure, emergency, or off-grid backup.

FAQ About Nanwind Solar NW-R series Solar Panel Suitcase Kit?

Can this charge my Jackery power station and car battery?

[A] Yes! The Kit includes: 4-in-1 cable (XT60/DC5521/Anderson/DC7909) for Jackery/Bluetti/EcoFlow and most of power stations; Anderson extension cable for 12V batteries; 10A PWM controller with alligator clips. Please note that some power stations may have a maximum input power limit, which could restrict the solar panel’s output efficiency.

Is the panel waterproof, can it be used in rainy or humid conditions? Can I leave it outside year-round?

[A] Yes, the solar panel is IP68 waterproof and can operate in rainy or humid conditions, but please take care that the included PWM controller is not waterproof. While IP68-rated, prolonged UV/rain exposure may degrade seals over 3-5 years. Store indoors during extreme weather to extend lifespan. Please also noted the included PWM controller is not waterproof. Recommend seasonal storage.

How does it perform in extreme heat (e.g., desert camping)? Why is my controller getting hot?

[A] Efficiency decreases by ~0.3%/°C above 25°C. In 40°C conditions, expect ~5% output loss. Aluminum frame dissipates heat better than plastic models; PWM controllers naturally reach 50-60°C during operation, keep in shaded, ventilated area. Do NOT cover.

How to clean the glass without scratching it?

[A] Just rinse with water and wipe with soft cloth, no special cleaning tools or products are needed.

Can I adjust the angle for winter sun? What’s the real-world output on cloudy days?

[A] Yes! Our kickstand supports multi-angle adjustments. For optimal performance: Lower angles target winter sun positions; Higher angles maximize summer sun exposure; Real output expect: 50-70W (100W model) – Partial clouds, 15-25W (100W model) – Heavy overcast. Tip: Angle panels toward brightest sky area.

Why doesn’t my solar panel reach its rated power?

[A] Solar panels achieve their “100W/200W” rating in lab-perfect conditions (1000W/m² solar irradiance, 25°C cell temperature, and perfectly perpendicular sunlight).In real life, you’ll typically see 70-90% of rated power due to: 1. Weather/Season: Clouds/Shade: 50%+ power loss; Winter Sun: 30-50% lower; Heat: Output drops ~5% on 95°F days; 2. Setup Issues: Wrong Angle → 20% loss; Dirty Panels → 25% loss; Long/Thin Cables →15% loss. Quick Fixes: Clean panels weekly with water + microfiber cloth; Adjust panel angle seasonally (summer: steeper); Keep controller/cables shaded and cool. This is normal – even professional solar farms rarely hit “lab perfect” numbers.

How should I store the panel when not in use to prolong its lifespan?

[A] Clean thoroughly; Dry in shade; Store in bag @ 10-30°C. Avoid basement humidity.

NW-200R Technical Specifications

Max Output Power 200W Open-Circuit Voltage 21.49V Short-Circuit Current 11.39A Operating Voltage 18.54V Operating Current 10.8A Operating Temperature Range – 40℃ ~ 85℃ Unfolded Size 53.86 * 0.71 * 33.62 inches Folded Size 26.93 * 1.42 * 33.62 inches Weight 20.2 lbs Materials 1.6mm Ultra-Thin Tempered Glass, Corrosion-resistant Aluminum, A+ 23.5% Monocrystalline Silicon Accessories 20A PWM controller*1, 1m 4-In-1 solar cable*1, 4m Alligator Clip cable*1, 3m Anderson extension cable*1, Protective bag*1, User manual*1

【Maximize Solar Power – 23.5% Efficiency & 12BB Premium Cells】Experience rapid charging for power stations, RV, or batteries with advanced 12BB Grade A+ monocrystalline cells—delivering up to 23.5% conversion rates. The ultra-thin 1.6mm tempered glass cuts weight by 40% (only 20.2 lbs), combining durability with effortless portability for outdoor and off-grid life.
【Built for Extreme Weather – True IP68 Waterproof & Reinforced Design】Withstands rain, snow, dust, and extreme wind (up to 130km/h) thanks to professional IP68-rated silicone sealing and reinforced aluminum frame. Survives 25mm hailstones and temperature swings; scratch-resistant matte glass stays clean with a quick wipe—ready for any adventure.
【Upgraded 20A PWM Controller & Universal Compatibility】Features a high-capacity 20A PWM controller (supports 12V/24V), ensuring stable charging for larger batteries. Includes a 4m alligator clip cable, 3m Anderson extension cable, and a 1m 4-in-1 connector (Anderson, XT60, DC5521, DC7909) for Jackery, EcoFlow, Bluetti, and more—plug and play for nearly any off-grid setup.
【Effortless Setup – Adjustable Kickstands & All Accessories Included】Set up in seconds using multi-angle kickstands for optimal sunlight at any site. Complete accessory set means no extra purchases: 200W solar panel, 20A PWM controller, 3m Anderson extension, 4m alligator clips, 1m 4-in-1 cable, protective Oxford bag, and user manual.
【Travel-Ready Protection & Reliable Support】Folds compactly (33.62” × 26.93” × 1.42”) in a rugged, reinforced Oxford case for easy carrying and storage. Backed by a 24-month warranty and 24/7 customer support—buy with confidence for RVing, camping, emergencies, or home backup.
